Real-time fluorescence quantitative PCR instrument
Model ：Q2
Product use
1. Quantitative/qualitative gene expression analysis;
2. Analysis of melting curve;
3. SNP genotyping;
4. MicroRNA analysis;
5. Methylation analysis;
6. Copy number variation;
7. Pathogen detection;
8. Detection of HBV, HCV, HIV, HPV, SARS, H1N1, AIDS, CSF and other diseases;
Product features
1. Compact shape, portable operation;
2. 16 channel design, which can handle up to 16 samples at a time;
3. Adopt multi-zone temperature control technology (2 points) to effectively improve temperature control accuracy and temperature uniformity;
4. Special optical processing can effectively obtain optical effects while avoiding edge effects without ROX correction.
Technical parameters
1. Sample flux: 16 holes, supporting 8 tubes;
2. Detection channel: 2;
3. Reaction system: 5-120μL；
4. Excitation light source: LED (maintenance free);
5. Excitation spectrum range: 400-1000nm;
6. Detection unit: photoelectric detector;
7. Applicable fluorescent dyes or probes: FAM/SYBR GreenI, VIC/HEX/CY3, ROX/Texas Red (optional), Cy5, TAMARA (optional);
8. Maximum heating rate: ＞3.5℃/s;
9. Maximum cooling rate: ＜3℃/s;
10. Module temperature range: 4-100℃ (the hot cover can automatically adjust the pressure);
11. Temperature control accuracy: ＜±0.1℃;
12. Temperature uniformity: ＜±0.2℃;
13. Temperature control technology: semiconductor cooler;
14. Noise: ＜45dB
15. Dimension (L × W × H): 200 ×135× 220mm；
16. Net weight: 3kg;
Configuration
1. One host;
2. A set of accompanying documents.
